Purus

Description

Direct Room Humidification

Guarantees accurate and highly efficient humidification performance in the smallest spaces

The ultrasonic principle makes the air humidifier Merlin Purus an absolute master in savings. For each kg humidification capacity, the humidifier on average requires an energy expenditure of merely 0.092 kW/h. The adiabatic humidification system withdraws and transforms energy from the room air therefore the created cooling effect can be used at a 1:1 ratio. Compared with isothermal systems, e.g. steam humidifiers, 93 % of energy costs are therefore saved.



Reviews

There are no reviews yet.

Be the first to review “Purus”

Your email address will not be published. Required fields are marked *

01642 777720

ENQUIRE NOW

APPLICATIONS:

  • Paint Shops and clean rooms
  • Electronics
  • Food Industry
  • Medical manufacturing facilities

OPTIONS

  • Duct hygrostat
  • Control cabinet with microprocessor controller
  • Various reverse osmosis systems
  • Online conductance measuring
  • Various transformers

Water is atomized by ultrasonic vibrations of 1.7 MHz into aerosols of 1 ¼m. An integrated fan distributes them via the air flow into the room, the aerosol mist (cold vapour) mixes with the ambient air, evaporates completely and is distributed efficiently and evenly throughout the room.






DETAILS

  • Corrosion-free stainless steel
  • Dry run, thermal and overflow protection
  • Oscillator of ceramic-piezoelectric material
  • Mains filter for protection against voltage peaks
  • Cross flow fan for aerosol dispersion
  • Hygiene management AquaDrain®
  • Disinfection programme Contra-Keim®



CONTROLLING

  • Hygrostat control
  • Constant controlling of all usual control signals
  • Adjustable capacity fan
  • Linear path control
  • Potential free output



TECHNICAL DATA

Type

Humidification capactiy Kg/h

Capacity VA

Voltage V/Hz

Weight kg

Dimensions (LxHxDmm)

PURUS 4

2.0

180

48V/50Hz

9.0

470 x 275 x 290

PURUS 6

3.0

240

48V/50Hz

11.0

580 x 275 x 290

PURUS 8

4.0

310

48V/50Hz

13.0

690 x 275 x 290

PURUS 10

5.0

370

48V/50Hz

15.0

780 x 275 x 290

PURUS 16

8.0

620

48V/50Hz

21.0

1050 x 275 x 290



OPERATION

Max air humidity

< 90% relative Humidity

Air temperature

5°C to 45°C

Pure water pressure

min: > 1 bar dynamic
max: < 6 bar static

Pure water quality

Totally desalinated

Conductance value pure water

> 20 µS/cm³

Low voltage

48 VAC – 50 Hz
